AAS-2610 AA Spectrophotometer For Detecting Trace Metal Elements
| MOQ: | 1 set |
| Price: | Negotiable |
| Standard Packaging: | Plywood packing |
| Delivery Period: | 5~8 working days |
| Payment Method: | ,L/C,T/T |
| Supply Capacity: | 500 sets/month |
Detail Information
Place of Origin
China
Brand Name
SHUOBODA
Certification
ISO/CE
Model Number
AAS-2610
Wavelength:
190nm-900nm
Monochromator:
C-T, Aberration
Spectrum Bandwidth:
0.2nm, 0.4nm, 1.0nm, 2.0nm For Option
Wavelength Accuracy:
±0.10nm
Wavelength Repeatability:
0.05nm
Baseline Shift:
Static ±0.001A/30min, Dynamic ±0.003A/30min
Highlight:
AA spectrophotometer for trace metal detection
,atomic absorption spectrometer with warranty
,trace metal element detection spectrophotometer
Product Description
AAS-2610 Atomic Absorption Spectrophotometer for Trace Metal Element Detection
The AAS-2610 Atomic Absorption Spectrophotometer is designed for precise detection of trace metal elements including Cu, Fe, Ca, Pb, Hg, Cr, Cd, Au, and more. This instrument complies with the GB/T21187-2007 professional standard for atomic absorption spectrophotometers, ensuring reliable performance and accurate results.
Performance Specifications
Optical System
| Wavelength Range | 190nm - 900nm |
| Monochromator | C-T, aberration |
| Spectrum Bandwidth | 0.2nm, 0.4nm, 1.0nm, 2.0nm (selectable) |
| Wavelength Accuracy | ±0.10nm |
| Wavelength Repeatability | 0.05nm |
| Baseline Shift | Static ±0.001A/30min, Dynamic ±0.003A/30min |
| Detector | Photomultiplier |
| Resolution | Separates Mn double (279.5nm & 279.8nm) in 0.2nm spectral bandwidth with peak energy ratio <20% |
Atomic System
| Characteristic Concentration (Cu) | 0.020μg/ml/1% |
| Detection Limit (Cu) | 0.003μg/ml |
| Burner | 100mm titanium metal, air premixed |
| Precision | RSD ≤ 0.5% |
| Sprayer | High efficiency glass atomizer |
| Atomizing Chamber | Corrosion resistant material |
| Position Adjustment | Flame burner optimum height, front and rear position adjustable, flame/hydride transfer in one minute |
| Safety Features | Multiple automatic protection systems, acetylene gas leakage alarm, closed system |
Analytical Methods
| Measurement Methods | Air-acetylene flame method, hydride generator atomic absorption method, oxygen-air acetylene flame method |
| Concentration Calculation | Standard curve method (1-3 times curve), auto fitting, standard addition method |
| Repetition Survey | 1-20 times, calculates average value, displays standard deviation and relative standard deviation |
| Printing Capabilities | Parameters print, data result print, graph print, summary report |
| Software Compatibility | Windows 98/2000/XP |
Instrument Parameters
| Voltage | AC 220V/50HZ |
| Power Consumption | 150VA |
| Weight | 70Kg |
| Dimensions | 1000mm (L) × 350mm (W) × 390mm (H) |
| Operating Temperature | 10℃ - 35℃ |
| Operating Humidity | ≤ 80% |
Standard Configuration
- Main host unit
- Low noise oil-free air compressor
- Operating software
- Complete accessories
- Wooden case packaging for transportation
Optional Accessories
- Hydride generator
- Oxygen enriched device
The AAS-2610 provides comprehensive trace metal analysis with exceptional precision and reliability, making it ideal for laboratory and industrial applications requiring accurate elemental detection.
